Welcome to the Leviton IPS02 manual, your guide to understanding and using the Single Pole Wide View Motion Activated Light Control effectively. This manual provides essential information to ensure proper installation, operation, and customization of the IPS02, helping you maximize its features and benefits for automatic lighting control in your space.
1.1 Overview of the Leviton IPS02
The Leviton IPS02 is a single-pole, motion-activated light control designed for automatic lighting management. It features a 30 ft. x 30 ft. coverage area and a 180-degree sensing angle, making it ideal for various spaces. The device is compatible with LED, CFL, and incandescent lights, offering both automatic and manual override functions for convenient operation.
1.2 Importance of Reading the Manual
Reading the Leviton IPS02 manual is crucial for understanding its features, installation, and operation. It provides safety precautions, troubleshooting tips, and warranty details, ensuring proper use and avoiding potential issues. The manual also explains how to customize settings for optimal performance, making it an essential resource for both installation and daily use.
Key Features of the Leviton IPS02
The Leviton IPS02 features advanced motion sensor technology, single pole wide view activation, and a 30ft x 30ft coverage area, ensuring reliable and efficient lighting control.
2.1 Motion Sensor Technology
The Leviton IPS02 utilizes advanced Passive Infrared (PIR) motion sensor technology to detect movement within its coverage area. This technology ensures reliable activation of lights upon detecting motion, providing hands-free operation. The sensor operates on a 180-degree angle, enhancing its ability to detect movement effectively in various settings, making it ideal for automated lighting solutions.
2.2 Single Pole Wide View Motion Activated Light Control
The Leviton IPS02 is a single-pole motion-activated light control designed for seamless integration into any space. Its wide view sensor provides a 180-degree detection angle, ensuring comprehensive coverage. This feature allows it to detect motion across a broad area, making it perfect for rooms where consistent lighting automation is desired, enhancing convenience and energy efficiency simultaneously.
2.3 Coverage Area and Sensing Angle
The Leviton IPS02 offers a coverage area of 30 feet by 30 feet, providing extensive motion detection in large spaces. Its 180-degree sensing angle ensures wide coverage, detecting motion effectively across the area. This combination of range and angle makes the IPS02 ideal for rooms requiring reliable and broad automated lighting control, enhancing both convenience and efficiency.
2.4 Compatibility with Different Light Types
The Leviton IPS02 is compatible with various lighting types, including LED, CFL, incandescent, and halogen bulbs. It also supports fluorescent ballasts and motor loads, offering versatility for different lighting setups. This broad compatibility ensures the IPS02 can be seamlessly integrated into diverse lighting systems, providing reliable performance across multiple applications without compromising functionality or efficiency.
Installation Instructions
Ensure power is turned off before starting installation. Connect wires according to the wiring diagram, then mount the device securely. Follow all safety guidelines and instructions carefully.
3.1 Pre-Installation Considerations
Before installing the Leviton IPS02, ensure the power is turned off at the circuit breaker. Verify compatibility with your lighting type, such as LED, CFL, or incandescent. Check the coverage area and sensing angle to ensure proper placement. Review the wiring diagram and ensure all connections match the manufacturer’s instructions. Always follow safety guidelines to avoid electrical hazards.
3.2 Step-by-Step Installation Guide
Turn off power at the circuit breaker. Remove the old switch and connect the wires to the IPS02, following the wiring diagram. Mount the device securely in the wall box. Adjust the sensor for optimal coverage. Turn the power back on and test the motion detection and light control functionality to ensure proper operation.
3.3 Wiring Diagrams and Connections
Refer to the wiring diagram for connections. Connect the line (hot) wire to the black terminal and the load (light) wire to the red terminal. The neutral wire connects to the silver terminal. Ensure all connections are secure and match the diagram. Turn off power at the circuit breaker before starting. This ensures safe and proper installation of the IPS02 sensor. Always verify compatibility with your lighting setup.
Adjusting Settings and Customization
The Leviton IPS02 allows customization of sensitivity, time delays, and light sensitivity. Adjustments can be made to tailor the sensor’s performance to your specific needs and preferences, ensuring optimal functionality in various settings.
4.1 Sensitivity and Time Delay Adjustments
The Leviton IPS02 allows users to fine-tune sensitivity and time delay settings for personalized control. Adjusting the sensitivity ensures accurate motion detection, while time delay settings determine how long lights stay on after motion ceases. These customization options optimize the sensor’s performance for specific environments and user preferences, enhancing convenience and energy efficiency.
4.2 Light Level Sensitivity Settings
The Leviton IPS02 allows adjusting light level sensitivity to customize when lights activate based on ambient light. By rotating the adjustment, you set the minimum light level required for automatic operation, ensuring lights only turn on when needed and preventing unnecessary activation during daylight, thus saving energy and enhancing functionality.
4.3 Manual Override and Automatic Functions
The Leviton IPS02 offers manual override, allowing lights to be turned on or off manually using the paddle switch, regardless of motion detection. This feature provides flexibility, enabling users to bypass automatic functions temporarily. The sensor can also be set to manual-on mode by adjusting the light level sensitivity fully counterclockwise, ensuring lights stay on until manually turned off.
Troubleshooting Common Issues
Troubleshoot issues like sensor malfunctions or lighting problems by checking sensor alignment, adjusting sensitivity settings, and ensuring proper wiring connections. Resetting the device or consulting the manual often resolves common glitches.
5.1 Sensor Not Detecting Motion
If the sensor isn’t detecting motion, ensure it’s powered on and check for obstructions blocking its field of view. Verify sensitivity settings are adjusted properly and the coverage area isn’t exceeded. Clean the sensor lens to remove dirt or debris that might interfere with detection. If issues persist, reset the device or consult the manual.
5.2 Lights Not Turning Off Automatically
If the lights fail to turn off automatically, check the time delay settings and ensure they are adjusted correctly. Verify that the ambient light sensitivity is set properly to detect natural light levels. Also, ensure the manual override feature isn’t engaged, and no obstruction is blocking the sensor’s field of view.
5.3 Issues with Manual Override
If manual override isn’t functioning, ensure the paddle is operated correctly. Check if the sensor is in manual-on mode by adjusting the light level sensitivity fully counterclockwise. If issues persist, cycle power to the device or reset the sensor by turning it off and on again to restore proper manual control functionality.
Warranty and Support Information
Leviton offers a 5-year warranty for the IPS02, covering defects in materials and workmanship. For support, visit Leviton’s website or contact their customer service for assistance and inquiries.
6.1 Leviton Warranty Details
Leviton provides a 5-year limited warranty for the IPS02, ensuring it is free from defects in materials and workmanship under normal use. The warranty applies to the original purchaser and includes repair or replacement at Leviton’s discretion. For details, refer to the warranty section in the manual or visit Leviton’s official website.
6.2 Contacting Leviton Customer Support
For inquiries or assistance with the IPS02, contact Leviton Customer Support at 1-800-824-3005 (US) or 1-800-405-5320 (Canada). Visit their website at www.leviton.com for more information or to submit a support request. Canadian customers can also write to Leviton Manufacturing of Canada Ltd., Attention: Quality Assurance Department.
Safety Precautions and Warnings
Always turn off power at the circuit breaker before installation. Do not touch electrical wires. Ensure proper grounding to avoid electrical shock. Follow all National Electric Codes and local regulations. Failure to comply may result in fire hazards or injury. Adhere to all safety guidelines provided in this manual;
7.1 General Safety Guidelines
Always turn off power at the circuit breaker before installation. Avoid touching electrical wires or components to prevent shock. Ensure proper grounding to maintain safety. Follow all National Electric Codes and local regulations. Use appropriate tools and wear protective gear. Never override safety features or bypass warnings. Failure to comply may result in injury or fire hazards.
7.2 Specific Warnings for Installation
Do not install near water or in damp environments. Ensure the area is dry to prevent electrical hazards. Use appropriate tools to avoid damaging the sensor or surrounding surfaces. Follow the manual’s instructions precisely to ensure proper installation and maintain warranty validity. Incorrect installation may void the warranty or cause malfunctions.
Compatible Models and Variants
The Leviton IPS02 is compatible with models such as IPS02-1LB, IPS02-1LG, IPS02-1LT, and IPS02-1LE, all offering similar functionality and features for motion-activated lighting control.
8.1 IPS02-1LB, IPS02-1LG, and Other Variants
The Leviton IPS02 series includes variants like IPS02-1LB, IPS02-1LG, and IPS02-1LT, each offering similar motion-sensing capabilities with slight design differences. These models cater to various lighting needs, ensuring compatibility with different fixtures and settings, while maintaining the core functionality of automatic lighting control through advanced PIR technology.
8.2 Differences Between IPS02 and IPV02
The IPS02 and IPV02 differ primarily in their operation modes. The IPS02 features Auto-On functionality, automatically turning lights on when motion is detected. In contrast, the IPV02 operates as a vacancy sensor, requiring manual activation but turning lights off automatically. Both models share similar coverage areas and compatibility with various light types, ensuring versatile applications.
Frequently Asked Questions (FAQs)
Explore common questions about the Leviton IPS02, including its operation, compatibility, and troubleshooting, to enhance your understanding and usage of the device effectively.
9.1 Can the IPS02 be Used as a Vacancy Sensor?
The Leviton IPS02 can function as a vacancy sensor by adjusting its settings. To enable manual-on operation, rotate the ambient light sensitivity fully counterclockwise. This allows lights to turn on manually and off automatically after a set period, perfect for applications requiring manual control with automatic shutoff for energy efficiency.
9.2 How to Reset the IPS02 Sensor?
To reset the Leviton IPS02 sensor, turn the power off at the circuit breaker for 10 seconds, then restore power. This resets all settings to factory defaults. Alternatively, press and hold the ON/OFF paddle for 10 seconds while the power is on to reset sensitivity and timing without losing custom adjustments.
9.3 Is the IPS02 Compatible with Smart Home Systems?
The Leviton IPS02 is primarily designed for manual or automatic operation and does not natively integrate with smart home systems. However, compatibility may be achieved through Leviton’s smart home devices or hubs. For specific integration details, consult Leviton’s compatibility list or contact their customer support for tailored solutions.
The Leviton IPS02 offers a reliable, efficient, and easy-to-use solution for motion-activated lighting control, enhancing convenience and energy savings in any space with its advanced features and customizable settings.
10.1 Summary of Key Points
The Leviton IPS02 manual provides comprehensive guidance on installing, configuring, and troubleshooting the Single Pole Wide View Motion Activated Light Control. It covers motion sensor technology, coverage areas, compatibility, and customization options, ensuring optimal performance and energy efficiency. The manual also includes warranty details and safety precautions for a seamless user experience.
10.2 Final Tips for Optimal Use
Adjust sensitivity and time delay settings to minimize false triggers and ensure energy efficiency. Regularly clean the sensor lens for accurate motion detection. Use compatible bulb types and check load ratings. Test manual override functionality periodically. Ensure proper installation and wiring to avoid malfunctions. Refer to the manual for troubleshooting common issues promptly.
